Description
SPECIFICATIONS:
Features:
- Monitoring interfaces for SpO2, temperature, pulse rate and PLETH.
- 2.8" colour TFT LCD in real time display, displaying in big font and big screen.
- Bluetooth wireless is very convenient to realize reviewing the measurements in big screen via connecting PC and to upload history data to PC for review, printing or storage.
- Unique software for telemonitoring by transmitting data synchronously via internet.
- Long time monitoring and sleeping monitoring.
- Storage/review trend data up to 3888 groups, data save time interval settable.
- Audio and visual alarm when parameters exceeded and sensor-off.
- Built-in rechargeable Li-ion battery, up to 15-hour running time.
Technical:
Oxygen saturation (SpO2):
- SpO2:
- Patient range: adult, child, neonate.
- Measurement range: 0-100%.
- Accuracy: ±2% (70%-100%), 0%-69% unspecified.
- Resolution: 1%.
- Pulse Rate:
- Measurement range: 0bpm-250bpm.
- Accuracy: ±2bpm.
- Resolution: 1bpm.
Temperature (Temp):
- Channel: 1
- Input: Skin surface thermal-sensitive resistor temperature sensor.
- Measurement range: 0°C-50°C.
- Accuracy: ±0.2°C.
- Resolution: 0.1°C.
Alarm:
- Mode: Audio, Visual.
- Type: Parameters exceeded and sensor-off alarm.
Storage and review:
- Trend data up to 3888 groups, data save time interval settable.
Display Mode:
- TFT LCD Screen: 2.8" 240 x 320 dot matrix colour TFT LCD.
Operation environment:
- Temperature:
- Working: 0°C-45°C.
- Transport and storage: -20°C-60°C.
- Humidity:
- Working: 15%-95% (non-condensing).
- Transport and storage: 10%-95% (non-condensing).
- Altitude:
- Working: 86kPa-106kPa.
- Transport and storage: 50kPa-106kPa.
Power requirements:
- Internal battery:
- Type: 3.7v Li-ion rechargeable battery.
- Operating time: 15hours.
- Recharge time: 8 hours.
- AC power adapter:
- Input: AC100V-240V, 50-60Hz, 5VA.
- Output: D.C.5V
