Description
SPECIFICATIONS:
Features:
- 8.4" colour TFT display.
- Suitable for adult, pediatric and neonatal patient.
- Basic parameters (ECG, SpO2, NIBP) in ad durable case for bedside monitoring and transport.
- Audible and visual alarms with adjustable alarm ranges.
- Networkable with Contec central monitoring system.
- Powerful data management and storage capacity.
ECG:
- Lead type: 5-Lead.
- Input: RA, LA, RL, LL, V.
- Sweep speed: 12.5mm/s, 25mm/s, 50mm/s,
- Accuracy: ±bpm or ±%, whichever is greater.
- Protection: Withstand 4000VAC/50Hz voltage in isolation against electrosurgical and defibrillation.
- S-T detection: Yes, Arrhythmia analysis: yes.
- Alarm: Yes, audible and visual alarm, alarm events recallable.
NIBP:
- Method: Oscillometry.
- Operation modes: Manual/Automatic/STAT.
- Measurement unit: mmHg/KPa selectable.
- Measurement types: Systolic, Diastolic, Mean.
- Over pressure protection: Yes.
SpO2:
- Measurement type: 0-100%
- Accuracy: 2digit(70-100%)
- 0-69% unspecified.
ETCO2:
- Continuously measure CO2 concentration in gas, and calculate end-tidal CO2 (EtCO2), inspired minimum CO2 (InsCO2), airway respiration rate (AwRR).
- CO2-MO1: the infrared light source up to 100,000h life is adopted which prolongs module life.
- CO2 measurement range: 0-150 mmHg.
- CO2 measurement accruracy:
- 0-40 mmHg: ±2mmHg.
- 41-70 mmHg: ±5% of reading.
- 71-100 mmHg: ±8% of reading.
- 101-150 mmHg: ±10% of reading.
- Note gate temperateure at 25°C
Respiratory monitoring range:
- CO2-MO1:2rpm-120rpm, accuracy: ±1rpm
- CO2-MO2:2rpm-150rpm, accuracy: ±1rpm
Standard Configuration:
- ECG, NIBP, SpO2, Resp, 2-Temp.
Optional:
- 2-IBP, ETCO2, Network, Thermal Recorder.
